16FN
Meet the 16FN, the cutting-edge fanless mini PC that combines silent operation with incredible performance. Originally developed as an R&D project, it’s built for tackling even the most demanding, graphics-intensive applications—without making a sound.
Powered by the Intel NUC platform, the 16FN doesn’t just deliver high performance; it stays cool and silent while doing it. Thanks to its rugged aluminum housing and efficient heat pipe system, heat is distributed quickly and effectively around the case. Even an Intel i7 CPU can run above base clock speeds without overheating—impressive, right?
Here’s what makes the 16FN even more unique:
- An internal AC/DC power supply (goodbye, bulky power bricks!)
- 1U rack mount panel, making it possible to install two units in a 1U rack cabinet
- Wall mounting holes for those hard-to-reach installs
- Power-over-Ethernet support
- Up to 3 NIC ports
- Optional RS232 port for added versatility
Oh, and did we mention customizability? If you’re looking for bespoke metalwork or branding options to make it truly yours, we’ve got you covered.
Whether for a tidy office setup, a powerful server rack, or a sleek wall mount, the 16FN is ready to perform. Get in touch to make it a perfect fit for your needs.
Case Specification
- Size (WxDxH): 220x180x44mm
- Weight: 3 KG
- Hot Swap HDD Bay: Not available with this case
- Power Supply: 110-230VAC, 12V-20 VDC or PoE++
- PCIE Slots: Not available with this case
- Front USB: 1x USB3.0
Options
Multiple Ethernet ports
Maximize Connectivity with up to 3 Ethernet ports in the 16FN. Providing critical network failover redundancy, and improved throughput, this option is essential for systems reliant on high availability.
Flexible installation options
Up to 2 in 1U rack mountable the 16FN is equally at home on your desk in the boardroom or wall mounted.
Power over Ethernet support
Ideal for installations in challenging environments, Power over Ethernet (PoE) streamlines the rackmount process by enabling both data and power to be fed through a single cable. Enjoy reliable connectivity, a decluttered comms cabinet, and the freedom of PoE++.
FAQs
If you have a specific question please contact us on 0333 880 4242.
NUC Environmental Specifications
- Ambient Operating 0°C to +50°C (Local ambient temperature inside the chassis) * Processor performance may automatically decrease when the system operates in the top 5 °C of the ambient operating temperature ranges above.
- Sustained Storage Limits (i.e. warehouse):-20°C to +40°C
- Short Duration Limits (i.e. shipping): -40°C to +60°C
If the external ambient temperature exceeds 40°C, further thermal testing is required to ensure components do not exceed their maximum operating temperature.
Note: The operating temperature of the board may be determined by measuring the air temperature from the junction of
the heatsink fins and fan, next to the attachment screw, in a closed chassis, while the system is in operation.
Note: Before attempting to operate this board, the overall temperature of the board must be above the minimum
operating temperature specified. It is recommended that the board temperature be at least room temperature
before attempting to power on the board. The operating and non-operating environment must avoid condensing
humidity.
